Albanyborg

Multipurpose Dry Cargo Carrier | Vessel | Finnish /Swedish 1A

Length o.a.: 143 | Beam: 21.5

Hold capacity (cbft) 707.633
DWCC (t) 15.750

Key features

Vessels in this series 15
Flag Dutch
Trading Area
Open hatch, fully box
Ice class IA
Polar code
Tween decks
Bulk heads
Dehumidifying system
High intake
Lifting capacity

Main particulars

Shipyard
Hudong-Zhonghua Shipbuilding Group Co. Ltd.
Classification
Lloyd's Register
Class notations
100 A1 Strengthened for Heavy Cargoes and Hold may be Empty, Container Cargoes in all Holds, on Upper Deck and on all Hatch Covers, *IWS LI, LMC, UMS, NAV1
Ice class
IA
Port of Registry
Delfzijl
Flag
Dutch
DWAT
17.294
DWCC Summer
15.750
Length over all
143
Breadth over all
21.5
Draft summer
9.69
Draft in ballast
5.490
TPC SSW
27.9
Air draft in ballast
35.4
Depth (moulded)
13.3
Distance WL-HC in ballast
10.5
GT
11.885
NT
5.650

Cargo capacities

Total cubic feet capacity
707633 ft3 grain/bale

Holds/hatches

2 Holds / 2 Hatches - Both types are: Fully openhatch - no understow / fully box and double skinned. Fully square - ex
cept box structures due to vessel's outer shape.
Vessel is equipped with MacGregor navire hydraulic steel pontoon hatches.

Hold #1

Dimensions
35.8 x 17.75 x 13.5
Luiken
35.8 x 17.75 x 13.5

Hold #2

Dimensions
52.1 x 17.75 x 13.5
Luiken
52.1 x 17.75 x 13.5

Electrical ventilaton

12 air changes per hour basis empty holds. Both holds fitted with dehumidifier system

Tank capacities

HFO
1350
MGO
215
Water ballast capacity
5490
Fresh Water
280

Speed/consumption

3 cranes fixed on portside - each with a capacity of 60 mts at a reach of upto 16m.
or a capacity of 40 mts at a reach of upto 28m.

The cranes can be combined to up to 120 mts but not the entire holds/ hatches can be served with this maximum lifting ca
pacity. Free distance between the cranes is 31 meters. Vessel fitted with lifting beam (weight about 10 tons).

Hoisting speed 60 mts SWL 40 mts SWL
Reeving 3 - fall 2 - fall
SWL 0 - 14 m per min. 0 - 22 m per min.
Empty hook 0 - 23 m per min. 0 - 35 m per min.

Fuel oil specification

VLSFO 0,5% ISO 8217:2010. MGO DMA 0,1% ISO 8217:2010. Within: ECA Area t/c operation to be responsible for sulphur limit compliance.

Engines

Main engine
Wartsila 6L46F 7500 600
Reduction gear
1x Flender, GCSP 1115
Propeller
Wärtsilä/ Lips, 4 blades, 4800mm
Bow thruster
750
