Lindeborg
Super Saimax | Vessel | 1C
Length o.a.: 82.5 | Beam: 12.5
Hold capacity (cbft)
160.000
DWCC (t)
3.500
Key features
Vessels in this series
12
Flag
Dutch
Trading Area
Open hatch, fully box
Ice class
IC
Polar code
Tween decks
Bulk heads
Dehumidifying system
High intake
Lifting capacity
Main particulars
Shipyard
Scheepswerf Peters B.V.
Classification
Bureau Veritas
Class notations
I HULL MACH General cargo ship -heavycargo (147 kN/m2) Unrestricted navigation AUT-UMS, ICE CLASS 1C, STRENGTHBOTTOM
Ice class
IC
Port of Registry
Delfzijl
Flag
Dutch
DWAT
3.778
DWCC Summer
3.500
Length over all
82.5
Breadth over all
12.5
Draft summer
5.35
Draft in ballast
1.682
TPC SSW
10
Air draft in ballast
13.5
Depth (moulded)
8
Distance WL-HC in ballast
6
GT
2.409
NT
993
Cargo capacities
Total cubic feet capacity
160000 ft3 grain/bale
Holds/hatches
1 Hold/ 1 Hatch, both types are: Fully open hatch - no understow. Fully box and double skinned.
Hold #1
Dimensions
54.59 x 10.3 x 8.15
Luiken
54.59 x 10.3 x 8.15
Electrical ventilaton
Hold ventilation abt.6 air changes per hour basis empty hold.
Hold is fitted with dehumidifier system.
Tank capacities
HFO
0
MGO
170
Water ballast capacity
1682
Fresh Water
26
Fuel oil specification
MGO DMA 0,1% ISO 8217:2010. Within: ECA Area t/c operation to be responsible for sulphur limit compliance.
Engines
Main engine
Caterpillar 3512 DI-TA 749 1600
Propeller
pitch propeller
Bow thruster
220
Vessels in this series
- Adamas 2010
- Andrea 2006
- Carolina 2008
- Denborg 2009
- Larixborg 2009
- Laurierborg 2006
- Lindeborg 2005
- Marietje Hester 2005
- Plataanborg 2009
- Sparborg 2004
- Susanne 2004
- Vlierborg 2005
