Lenneborg

Cargo capacities

Holds/hatches

3 Holds/ 3 Hatches, all types are: fully open hatch. Box shaped and double skinned.

Strenghts:
Max pressure tanktop 15,00 mts/sqm
Max pressure weatherdeck 2,20 mts/sqm (hatch no. 1)
3,50 mts/sqm (hatch no. 2 and 3)
Including 8 heavy load points for pointloads upto 60 mts/sqm.

Cement Holes: (type B)
Positions of cement holes in the following hatches on starboard site:
Hatch no. 2, 6 and 10: 2,91 m of front hatch and 2,25 m of site hatch.
Positions of cement holes in the following hatches on port site:
Hatch no. 1, 3 and 7: 2,65 m of front hatch and 2,25 of site hatch.

Cement holes by dm:
Outsite 530 mm
Inside 410 mm
Each hole 12 bolts M20, length of bolt 60 mm.

Hold #1

Hold #2

Hold #3

Electrical ventilaton

Abt. 6 air changes per hour basis empty hold. Holds are fitted with dehumidifier system.

Tank capacities

Fuel oil specification

VLSFO 0,5% ISO 8217:2010. MGO DMA 0,1% ISO 8217:2010. Within: ECA Area t/c operation to be responsible for sulphur limit compliance.

Engines
